R10,499.00R9,010.00 incl. VAT
Seamlessly retrofit your existing DIN-sized stereo with a value-packed RA70 Series marine stereo from Fusion®. The RA70 Series includes two marine stereos — MS-RA70 and MS-RA70N.
 |
 |
 |
 |
 |
| Seamlessly retrofit your existing DIN-sized cutout without needing to reconfigure dash space. | Optically bonded monochrome LCD improves screen visibility. | Built-in Class-AB amplifier delivers efficiency with reduced distortion. | Multi-Zone™ Technology gives you control of two separate audio zones. | Control your music from a compatible multifunction display (MFD)1, smart device or Garmin watch. |
Take advantage of the many source options available, including Bluetooth® technology, DAB+ radio, AM/FM radio, AUX and USB connections.
General |
|
| Dimension | 7.4″ x 2.36″ x 4.87″ (188 x 60 x 123.5 mm) |
| Weight | 1.23 lbs (556 g) |
| Water rating | IPX7 (front panel only, when properly installed) |
| Display | 2.6″ optically bonded monochrome LCD |
| Operating temperature | 32° to 122° F (0° to 50° C) |
| Current (max) | 15 A |
Networking |
|
| NMEA 2000® LEN | See Additional |
| Bluetooth® wireless range | Up to 10 metres (30 ft) |
| ANT® wireless range | Up to 10 ft (3 metres) |
| Wireless frequencies/protocols | Bluetooth®: 2.4 GHz @ +1.9 dBm nominal ANT®: 2.4 GHz @ +1.9 dBm nominal |
Audio |
|
| Amplifier | Class-AB (4 ohm) |
Electrical features |
|
| POWER INPUT | 10.8 – 16 VDC |
| Compass safe distance | 5.9″ (150 mm) |
Stereo features |
|
| Peak power | 200 watts |
| Rated power output (4 Ohm) | 26 watts RMS x 4 @ 14.4 V input < 10% THD |
| Control | Yes (see Additional) |
| Multi-Zone™️ technology | 2 zones |
| Bluetooth® wireless technology | Yes |
| ANT® wireless technology | Yes |
| SiriusXM-ready | See Additional |
| DAB+ ready | See Additional |
| Supports NRX wired remote | See Additional |
| Multi-language interface | Dutch, English, French, German, Italian, Spanish |
| Software updates | USB |
| Warranty | 1year |
Sources |
|
| Supported sources | AM, FM, Bluetooth®, USB audio, iPhone®, iPod®, AUX x1, AOA MS-RA70NSX: SiriusXM-Ready (U.S. only, requires optional SiriusXM Connect vehicle tuner) MS-RA70 and MS-RA70N: DAB+ ready (available in Europe and Australia only) |
Connections |
|
| Auxiliary inputs (RCA) | 1 |
| NMEA 2000® ports | 1 (MS-RA70N and MS-RA70NSX only) |
| USB 2.0 ports | 1 |
| SiriusXM ports | 1 (MS-RA70NSX only) |
| Antenna ports | 1 |
| Speaker connections | 4 (2 zone amplified) |
| RCA Pre-out (left, right and subwoofer) | 2 zones (requires external amplification) |
| Line out | 2 (L + R per zone, requires external amplification) |
| Subwoofer out | Zone (requires external amplification) |
Additional |
|
| Additional | NMEA 2000® LEN: 1 (50 mA), MS-RA70N and MS-RA70NSX only Fusion-Link™ control: MS-RA70: smart device and Garmin watch; MS-RA70N and MS-RA70NSX: MFD, smart device and Garmin watch SiriusXM-ready: MS-RA70NSX only DAB+ ready: MS-RA70 and MS-RA70N only Supports NRX wired remote: MS-RA70N and MS-RA70NSX only |
